TFT-H080A16WUIFLKC40 | 8 Inch High Brightness TFT LCD Display With MIPI Interface

Introducing our premium 8-inch High Brightness TFT LCD display, engineered to deliver exceptional visual performance and robust interactivity for demanding industrial, automotive, and outdoor applications. This display is built around a true High Brightness TFT LCD core, boasting an impressive 1000 nits of brightness. This exceptional luminance ensures perfect screen readability and vibrant color reproduction even under direct sunlight or in high-ambient light conditions, making it an ideal solution where visual clarity is non-negotiable.

The cornerstone of this module is its superior High Brightness TFT LCD panel, which features a high resolution of 1920 x 1200 (WUXGA). Coupled with an IPS (In-Plane Switching) viewing angle technology, it provides consistent, accurate colors and crystal-clear imagery from virtually any perspective up to 178 degrees. The rugged design of this High Brightness TFT LCD is further reinforced by an impressive ESD protection rating of 8kV and a wide operating temperature range of -30°C to 80°C, guaranteeing reliable performance in electrically noisy and environmentally challenging settings.

Beyond its brilliant display capabilities, this module integrates a highly responsive multi-touch capacitive touch panel, driven by the advanced GT911 controller. This offers a smooth, intuitive user experience akin to modern smartphones, supporting gestures like pinch-to-zoom and swipe. The sleek, flush surface of the capacitive touchscreen is not only more durable but also easier to clean compared to resistive alternatives. , it offers a large, high-brightness viewing real estate in a space-efficient form factor.

Designed for seamless integration with popular microcontroller platforms such as C8051, Arduino, and STM32, and powered by a single 3.3V supply, this all-in-one display solution combines stunning high-brightness visuals with modern touch interactivity. It is the perfect choice for developers and engineers building next-generation human-machine interfaces (HMI) that require unwavering performance and superior user interaction.
